Advantech PCA-6775
Chipset
Socket
FSB speed 133MHz
Form factorSingle Board Computer
Dimensions185 mm x 122 mm
Max VRAM size32MB
Cache
None/Integrated in the CPU
Max RAM size
512MB
RAM type 144-pin SDR SO-DIMM
PSU connector
I/O ports1x
CF Card Slot
1x
Floppy interface
1x
GPIO
2x
IDE interface
1x
LVDS
1x
PS/2 KB+MS Combo
1x
Parallel
1x
RJ-45 LAN
2x
Serial
4x
USB 1.x
1x
VGA
Expansion slots1x
16-bit ISA
Last updated 2024-03-13T18:27:47Z
Board info score is 8.3/10
Chips
-> Chipset part
-> Network
-> Video
CPU family support
No BIOS files available
7 drivers available
Name
Version
Arch
OS support
Size
Filename
Name
Version
V5.00
Arch
x86
, PPC
OS support
MS-DOS
Mac OS X
NetWare Server 3
NetWare Server 4
Netware Client32
SCO Unix - OpenServer
Windows 2000
Windows 3.1x
Windows 9x
Windows NT 3.5x
Windows NT 4.0
Size
3.343MB
Filename
Name
Version
1.0
Arch
OS support
MS-DOS
Windows 2000
Windows 9x
Windows NT 4.0
Windows XP/2k3
Size
490.931KB
Filename
Name
Version
N/A
Arch
x86
OS support
MS-DOS
Size
227.749KB
Filename
Name
Version
5.70d
Arch
x86
OS support
Windows 2000
Windows 9x
Windows NT 3.5x
Windows NT 4.0
Windows XP/2k3
Size
3.925MB
Filename
Name
Version
V3.00a
Arch
x86
OS support
MS-DOS
Windows 2000
Windows 9x
Windows NT 4.0
Windows XP/2k3
Size
1.867MB
Filename
Version
Arch
OS support
Size
Filename
Version
Arch
OS support
MS-DOS
OS/2 Warp 4.x
Windows 9x
Windows NT 4.0
Windows XP/2k3
Size
4.28MB
Filename
Version
Arch
x86
OS support
MS-DOS
OS/2 Warp 4.x
Windows 2000
Windows 9x
Windows NT 3.5x
Windows NT 4.0
Windows XP/2k3
Size
4.253MB
Filename
2 board documents available
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Image 1 of 4 (evasive)
Image 2 of 4
Image 3 of 4
Image 4 of 4
