Aewin CB-6970 series
Logs
chipChipset
cpuSocket
NanoBGA2 (BGA400)
speedFSB speeds
400MHz800MHz
moboForm factor
EBX/Little Board/Biscuit SBC 5.25" (max 203 x 146 mm)
dimDimensions
203mm x 146mm
ramMax VRAM size
64MB
chipCache
None/Integrated in the CPU
ramMax RAM size
1GB
ramRAM type
DDR2 UDIMM
pwrPSU connector
DC Jack (12V)
tag Also known as
connI/O ports
1x
CF Card Slot
1x
Floppy interface
1x
GPIO
1x
IDE interface
1x
PS/2 KB+MS Combo
1x
Parallel
4x
RJ-45 LAN
2x
Serial
8x
USB 2.0
1x
VGA
cardExpansion slots
1x
32-bit mini-PCI
notes Notes

CB-6970A-150 two LAN ports Limitation: Without PXE function, with RAID function VIA C7TM 1.0GHz Processor/Four Intel® 82551ER LAN, w/o bypass function

CB-6970B-100 Limitation: Without PXE function, with RAID function VIA EdenTM (V4) 400MHz Processor/Four Realtek® 8139CL+ LAN, w/o

CB-6970C-040 bypass function Limitation: with PXE function, without RAID function (only SATA IDE)

Last updated 2026-02-20T06:38:44Z
Board info score is 7.9/10
chip Chips
-> Chipset part
VIA VT3344 (CN700) VIA VT8237R Plus
-> Network
Intel 82551ER (PCI Fast Ethernet)
-> Super I/O
Winbond W83627HG
cpufam CPU family support
bios No BIOS files available
drv 16 drivers available
Name
Version
Arch
OS support
Size
Filename
Name
Version
2003
Arch
x86
OS support
MS-DOS OS/2 2.x
Size
554.797KB
Filename
Name
Version
2003
Arch
x86
OS support
Windows 2000
Size
12.279MB
Filename
Name
Version
2003
Arch
x86
OS support
Windows 9x
Size
1.422MB
Filename
Name
Version
2003
Arch
x86
OS support
Windows 9x
Size
8.693MB
Filename
Name
Version
2003
Arch
x86
OS support
Windows 9x
Size
1.525MB
Filename
Name
Version
2003
Arch
x86
OS support
Windows 9x
Size
8.909MB
Filename
Name
Version
2003
Arch
x86
OS support
Windows NT 4.0
Size
7.553MB
Filename
Name
Version
N/A
Arch
OS support
Windows 2000 Windows XP/2k3
Size
12.16MB
Filename
Name
Version
11.1
Arch
x86 , x64
OS support
MS-DOS Windows 2000 Windows 9x Windows XP/2k3
Size
36.353MB
Filename
Name
Version
4.49V
Arch
x86
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP/2k3
Size
1.369MB
Filename
Name
Version
5.24A
Arch
OS support
Windows 2000 Windows 9x Windows XP/2k3
Size
12.683MB
Filename
Name
Version
5.70d
Arch
x86
OS support
Windows 2000 Windows 9x Windows NT 3.5x Windows NT 4.0 Windows XP/2k3
Size
3.925MB
Filename
Name
Version
3.7
Arch
x86
OS support
Linux MS-DOS Mac OS X NetWare Server 3 NetWare Server 4 Netware Client32 SCO Unix - OpenServer UnixWare Windows 2000 Windows 3.1x Windows 9x Windows NT 4.0 Windows XP/2k3
Size
4.26MB
Filename
Name
Version
16.01.23.24
Arch
OS support
Windows 9x
Size
7.717MB
Filename
Name
Version
5.40A
Arch
x86 , x64
OS support
Windows 2000 Windows 9x Windows NT 4.0 Windows XP/2k3
Size
10.793MB
Filename
Name
Version
6.14.10.0380
Arch
x86
OS support
Windows 2000 Windows XP/2k3
Size
3.197MB
Filename
doc 1 board document available
Release date
File
Logs
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Chip
Release date
File
Logs
Family
Release date
File
Logs
Family
Release date
File
Logs
image1 Image 1 of 2 (Aewin)
image2 Image 2 of 2 (Aewin)
